1600x1400mm EPS Shape Moulding Machine For Fruit Packing Box

Ask Lasest Price
Brand Name :	PIN SHENG
Model Number :	PSSM100-200B
Price :	negotiation
Payment Terms :	T/T LC
Supply Ability :	10pcs per month
Delivery Time :	6-10days

Add to Cart

Product Details
Company Profile

1600x1400mm EPS Shape Moulding Machine For Fruit Packing Box

EPS Shape Moulding Machine for Fruit packing box

1. This machine applies PLC and HMI,advanced moulding technique and can produce various shapes of EPS products.

2. This machine can provide different kinds of foam articles with lower moisture content, high foaming speed and lower consumption of energy.

3. There are four kinds of operating mode (automatic,semi-automatic,pause-startup and manual operation)with safe-guard protective device to ensure safe operation.

4. This machine applies advanced electrical and hydraulic integration system,which improves the moulding speed,lowers the energy consumption remarkably and reduces the environmental pollution.

Item	Unit	PSSM160B	PSSM170B	PSSM180B
Mould Dimension	mm	1600X1400	1700X1500	1800X1600
Max Product Dimension	mm	1450X1350X350	1550X1350X350	1650X1450X350
Stroke	mm	170-1420	170-1420	120-1370
Steam Inlet	mm	DN100	DN100	DN100
Steam Consumption	t/t	(10-15t)Steam of 1t Material
Cooling Water inlet	mm	DN80	DN80	DN80
Cooling Water Consumption	kg/cycle	60-180	70-190	90-200
Compressed Air Inlet	mm	DN40	DN50	DN50
Compressed Air Consumption	m³/cycle	2	2.2	2.4
Vacuum Pump Capacity	m³/h	230	280	280
Drainage Port	mm	DN150	DN150	DN150
Connected Load	kw	17	17	17
Outside Dimension	mm	4600X2500X4000	4600X2600X4100	4600X2700X4200
Weight	kg	6000	6500	7000
Cycle Time	s	70-160	80-170	80-180

1600x1400mm EPS Shape Moulding Machine For Fruit Packing Box
FAQ
1. Where is your factory located?
We have 2 production plant, one plant locates in Hangzhou which professionally producing EPS/EPP/ETPU machine. Another factory locates in Jiangsu Provide which producing EPS/EPP/ETPU mould. Both two factories are pretty close to the Shanghai port for easiest transportation.

2. Do you have detailed and professional installation manual?
We will provide very detailed installation manuals and videos, and the service until you are satisfied

3. Are you a trading company or a manufacturer?
We are manufacturer.

4. How long is your delivery time?
Normally delivery time is 30~45 days.

5. How many years have your company made this kind of equipment?
More than 10 years.

6. Can I only buy some spare parts from you?
Yes, we also provide all kinds of spare parts that relatives to our machine.

7. How do you pack the equipment?
We will strengthen and protect the equipment to ensure that they will not be damaged during transportation

8. Can you send your staff to install the equipment for us?
Under normal conditions, it is possible. Now it is an epidemic situation.
We will try our best to assist in case wecannot send technician in time. We will also conduct video connections with guests to teach them to install them in place.

9. Can you can design the equipment according to our size?
Yes, it is acceptable

10. How many production lines in your factory?
We have total 10 production line.
